With this dimmer you can dim the most LED lighting from 0 to 100%. An additional setting option makes it possible to adjust the brightness min / max. Suitable for GIRA, Berker, Jung and Busch Jaeger cover frames and rotary knob. Read more.
This LED dimmer is suitable for dimming the most common LED lamps and dimmable LED lighting that work with phase cutting (trailing edge). You can set the minimum dim position by means of an additional setting option. Light control provides more well-being and comfort by being able to vary the light as needed. When you dim, you also save energy and the lifespan of the light sources is longer. The LED dimmer has a standard size and fits in all common in- and surface-mounted boxes. Will be delivered without cover frame and central plate, you can choose the brand you want to use for this, it is suitable for cover plates of Berker, Elso, Gira, Jung and Peha and Busch Jaeger.
Voltage: 220-240V
Frequency: 50Hz
Silently dims back
Dim method: Phase cut-off dimmer
Dimmable LED lamps 5-150W
Dimmable halogen 20-300W with electronic transformers.
Incandescent bulbs 20-300W
Cover: The shaft diameter is 4 mm suitable for cover plates from Berker, Elso, Gira, Jung and Peha.
The adapter bush supplied (from dia.4 to dia.6 mm) also makes it possible to use cover plates from Busch Jaeger.
